ESB 3.6K3U
- Gamintojas: ESB
- Kategorijos: KOMPONENTINIAI GARSIAKALBIAI AUTOMOBILIŲ TECHNIKA
399.00€
- Kaina be PVM: 329.75€
2-Way Mid-High Unit
Main Features
– This special and exclusive component driver is a concept conceived way back in 1970’s. Its aim is to concentrate medium and tweeter emissions in a single virtual point. This minimizes phase delays and irregularities at the crossover point.
– The neodymium magnet is high grade type to eliminate magnetic losses at elevated temperatures and to concentrate more force in less space.
– The tweeter has a silk-impregnated, thin fabric dome diaphragm for a smooth sound, with an outer suspension covered with a high-loss damping material to eliminate edge vibration and resonance.
– Pressed paper cone with waterproof treatment (midrange) for the ideal marriage between lightness, stiffness and the ability of the cone to dampen any unwanted vibration.
– The voice coil uses an aluminum support and a double layer winding technology of copper wire with an aluminum core.
Technical Specifications
– Nominal Impedance: 4 Ohm
– Nominal Power: 60 (mid), 80 (tw) W
– Transient Power: 120 (mid), 160 (tw) W
– Frequency Response: 130 Hz ~ 25 KHz
– Sensitivity: 86 (mid), 91 (tw) dB 2.83v/1m
6.5″/165 mm Mid-Woofer
– ABS basket reinforced with fiberglass. The basket has been engineered to obtain the maximum in terms of torsional rigidity (resistance to bending), but at the same time, offers the minimum resistance to air passage.
– Pressed paper cone with waterproof treatment. It is widely recognized that cones made of paper are the ideal marriage between lightness, stiffness and the ability of the cone to dampen any unwanted vibration (read: distortion).
– High damping, single wave rubber surround. The Perbunan® rubber edge is much more stable with temperature changes than standard rubber.
– The 25 mm voice coil uses an aluminum support with a double layer winding technology of copper wire with an aluminum core.
– High grade ferrite magnet, a type of magnet with significantly higher performance than “standard” magnets.
Technical Specifications
– Nominal Impedance: 4 Ohm
– Nominal Power Handling: 120 Watt
– Transient Power: 240 Watt
– Frequency Response: 65 Hz ~ 9 KHz
– Sensitivity: 91.5 dB 2.83v/1m
Susiję produktai
KENWOOD KFC-E130P
KENWOOD KFC-E130P TECHNINĖS CHARAKTERISTIKOS 2-jų juostų komponentiniai garsiakalbiai 13cm polipropi..
ALPINE S2-S80C
S-serijos 20cm (8”) komponentiniai 2-jų juostų garsiakalbiai Naujai suprojektuoti ir sertifikuoti H..
GROUND ZERO GZRC 165.3SQ
Ground Zero Radioactive SQ lineup is designed and produced for one goal only. Best possible sound qu..
GROUND ZERO URANIUM GZUC 165.3SQ
