PROJECT PRE BOX RS DIGITAL SILVER
- Gamintojas: PRO-JECT
- Kategorijos: AUSINIŲ STIPRINTUVAI AUSINĖS NAMŲ TECHNIKA
1,199.00€
- Kaina be PVM: 990.91€
High-end pre-amplifier, DAC, Headphone amp
The most universal & future-proof high-end pre-amplifier, DAC, headphone amp!
Pre Box RS Digital combines all features of DAC Box RS plus a very linear pre-amplifier with both solid-state and tube output stages, that can be selected alternatively. As in all our top-class digital products, we use PCM1792 DAC chips from Texas Instruments, but here we use 2 pieces in a dual differential mode to achieve ultimate fidelity. As a selectable feature, a second DAC chip from Texas Instruments is on board, that can handle 32bit/384kHz. A high-class headphone output with selectable impedance for a perfect match to your headphones is also provided. Pre Box Digital RS offers 3-dimensional sound-staging, perfect micro dynamics and ultimate resolution combined with flexibility to use a wide range of digital and 1 analogue sound sources. Perfectly combined with Pro-Ject CD Box RS disc drive, Pre Box RS Digital will give outstanding sound experience, because of a I²S connection provided via RJ45, that is able to give jitter-free disc playback.
Technical Specifications
| DAC | DAC1 – 2 x PCM1792 24bits/192k Hz; |
| DAC2 – PCM5102 32bits/384k Hz | |
| Tubes | 2 x 6922 EH |
| Digital inputs | 1 x USB 2.0 Audio 32/384 + DoP-DSD 64/128 |
| 1 x RJ45 Sonic I2S for CD Box RS in Sonic Mode | |
| 2 x S/PDIF 24/192 | |
| 4 x S/PDIF Optical 24/96 | |
| 1 x AES/EBU balanced 24/192 | |
| Line-level input | 1 RCA/phono sockets |
| Input impedance | 33 kohms |
| Analog outputs | Pre-out (XLR & RCA), Headphone (6,35mm jack) |
| Headphone impedance | 5 / 20 / 50 Ohms switchable |
| Analog input sensitivity | 1.6V RMS for full headphone output |
| Frequency response | 20 Hz – 50 kHz (+ 0dB/- 0.1 dB) |
| Signal to noise ratio | -100 dB (IEC-A) |
| THD | 0.005% solid state output/ 0.25% tube output |
| Master clock output | 16.9344 MHz for CD Box RS in Sonic Mode |
| Outboard power supply | 20 V/3 A DC suitable for your country’s mains supply |
| Power consumption | 300 mA solid / 850 mA tube / 90 mA standby |
| Dimensions W x H x D | 206 x 72 x 210 mm with sockets |
| Weight | 1950 g without power supply |
