AMPIRE KV-CRAFTER-2, GALINIO VAIZDO KAMERA SKIRTA VW CRAFTER/MAN TGE M

Specialiai  VW Crafter (2-os kartos) modeliui sukurta galinio vaizdo kamera. Kamera pasižymi geromis veikimo savybėmis. Kamera taip pat tinka identiškam MAN TGE modeliui (Nuo 2017 m.)

• Raiška: 648x488 px.
• Vaizdo sensorius: CMD-III.
• Vaizdo formatas: NTSC.
• IP68 atsparumo vandeniui standartas.
• Kameros kabelio ilgis: 10 m.

APRAŠYMAS

Vehicle-specific reversing camera for the Volkswagen Crafter 2 or the identical MAN TGE from 2017. The camera is mounted over the factory brake light glass. In the second generation of this camera, an improved camera chip with a significantly higher resolution was used.

TECHNINIAI DUOMENYS

SPECIFIKACIJOS

- Mirrored image reproduction
- Auxiliary lines: switched on at the factory (can be switched off by separating a cable loop)
- Image sensor: CMD-III. "High performance digital super clarity image sensor
- Resolution 648x488 pixels
- Viewing angle 170 °
- vertical adjustability of the camera 20 °
- Picture format: NTSC
- 580 lines resolution
- IP68 waterproof
- Integrated infrared lighting for perfect night vision
- Operating voltage: 9-16 volts DC
- Power consumption: max. 150mA
- Operating temperature: -30 ° to 70 ° C
- Minimum lighting: 0 lux
- Color: Black
- Cable length: 10 meters
- E approval E9-10R-05.1652
- CE approval EN 55022: 2010; EN 61000-3-2: 2006 + A1: 2009 + A2: 2009; EN61000-3-3: 2008; EN 55024: 2010
- FCC approval ANSI C63.4-2003

DOKUMENTAI

INSTRUKCIJOS

User Manual (DE).
