MARANTZ SACD 10 – AUKŠČIAUSIOS KOKYBĖS SACD/CD GROTUVAS SU INTEGRUOTU AUKŠTOS KOKYBĖS DAC. DISKŲ PALAIKYMAS: SACD, CD, CD-R/RW, DVD-ROM (SU MUZIKOS FAILAIS)
- Gamintojas: MARANTZ
- Kategorijos: CD GROTUVAI GARSO STIPRINTUVAI BEI GROTUVAI NAMAMS NAMŲ GARSO APARATŪRA
-
10,999.00€
- Kaina be PVM: 9,090.08€
The reference-standard SACD 10 is crafted to be the very best using a fully Marantz designed SACDM-3 transport mechanism for maximum rejection of resonance.
- Marantz SACDM-3 transport mechanism
- DSD 256 and PCM 384 / 32 support
- Headphone amplifier
- Dual power supplies with toroidal transformers
- OLED display
- Marantz Industrial Design
SACD 10
From the triple-layer aluminum chassis with copper shielding to entirely original multi-layer PCBs, isolated sub-enclosures, and HDAM module, SACD 10 is the product of decades of expertise in audio engineering, setting a new benchmark with meticulous construction, state-of-the art technologies, and remarkable design.
SACD 10 retains the sonic Marantz signatures of warmth, spaciousness, and resolution. However, advances in design and precise tuning by the Sound Master result in the purest expression of the Marantz sound ever. As a result, the listener experiences more detail than ever before.
Made for the ultimate CD and SACD enthusiast, SACD 10 is engineered with updated Marantz Musical Mastering and a next generation HDAM module for impeccably detailed audio reproduction.
SACD 10 supports balanced sources via USB-A and USB-B DAC, plus DSD 256 and PCM 384 / 32 support. Connectivity options also include coaxial and optical digital outputs and inputs, and fixed level XLR and RCA analog outputs.
With a brushed aluminum control surface, spun finish details, a thick-section aluminum structure, copper-plated, triple-layered chassis, , SACD 10 is in a class of its own. Available in two colorways, Marantz Black and Marantz Champagne to complement any setting.
- Unit (W × H × D mm)440 × 192 × 442
- Cabinet Size440 × 192 × 422
- Net weight33.0kg
- Packaging Dimensions (W × H × D mm)600 × 379 × 540
- Packaging gross weight38.4kg
- Carton Color1 Color (Material color: Brown Printing: Black)
- Panel ColorBlack / Marantz Champagne
- Front (Center) PaneAluminum
- Back-shellAluminum
- Front panel illuminationYes (All sides, Dimmer)
- Side coverAluminum (Thickness: Max 15.8mm)
- Top coverAluminum (Thickness: 12mm)
- Bottom Layer / Bottom plateTriple layer copper-plated
- FootSolid aluminum with Copper
- Frequency ResponseSACD: 2Hz–50kHz (-3dB)
CD: 2Hz–20kHz (±1.0dB) - Harmonic distortionSACD: 0.0004%
CD: 0.0015% - S/NSACD: 118dB
CD: 116dB - Dynamic rangeSACD: 112dB
CD: 98dB - Line Output LeveUNBALANCED : 2.0Vrms
BALANCED : 4.0Vrms - Headphone Output Level130mW / 32 ohms
- Power Consumption55W
Less than 0.3W (at Standby)
- Output CircuitNew HDAM
- Power TransformerToroidal
- Headphone CircuitDiscrete
- H/P Amp Gain SettingYes (Low / Mid / High)
- H/P On.Off SettingH/P Off automatically, when in use
- DAC CircuitNew MMM-Conversion
- DitherMMM-Stream (Dither 1, 2, Off)
- Noise ShaperMMM-Stream (Balanced, Natural, Dynamic Music, Dymanic Voice)
- Digital FilterMMM-Stream
Filter 1, 2 Selectable - Jitter ReducerYes
- DAC Master Clock Design (SACD, USB-A, USB-DAC)Yes
- Asynchronous mode (for USB-B input)Yes
- Isolator (for USB-B input)Yes (Complete Isolation System Duo)
- Fixed Analog Output (RCA)Cinch × 1
Thick nickel plated Maching copper L/R independent terminals - Fixed Balanced XLR Output1
- Optical input / output (Maximum Support)2/1
4.1 kHz - 192 kHz - Coaxial input / output (Maximum Support)2/1
4.1 kHz - 192 kHz - Headphone OutputYes (φ6.3 x 1)
- Remote Control Bus TerminaYes
- Remote Internal / External SwitchYes
- AC InletYes
- Accessory BoxYes
- Remote ControllerRC004PMND
- BatteryYes (AAA ×2)
- Power CordYes (ALL region : Audio Grade : OFC)
- OtherStereo RCA Cable ×1
emote connector cable ×1
