AUDIOPHONY MPX6 MIKŠERINIS PULTAS SU KOMPRESORIUMI, EFEKTAIS IR USB/SD/BT GROTUVU

Specifikacijos

Mono :

• Microphone inputs : Balanced
• Frequency response : 10Hz - 30KHz, +/-3dB
• THD (THD&N) : 0.03% @ +4dBu, 22Hz-20KHz A weighted
• Compression : Gain: 0-9dB, Threshold: 20dB 5dB
• S/N ratio : 115 dB
• Line inputs : Balanced
• Frequency response : 10Hz - 30KHz, +/-3dB
• THD (THD&N) : 0.005% @ +4dBu, 22Hz-20KHz A weighted
• Maximum gain : 75 dBu 75 dBu Mic input Master output

Stereo :

• Line inputs : Balanced/Unbalanced
• Frequency response : 10Hz - 55KHz, +/-3dB
• THD (THD&N) : 0.005% @ +4dBu, 22Hz-20KHz A weighted

Impedances:

• Microphone inputs: 1,4 K Ohms
• Line inputs: 10 K Ohms
• Other inputs: 10 K Ohms ou plus
• Recording input: 1 K Ohms
• Other outputs: 120 Ohms

Mono channels EQ:

• High +/-15dB @ 12 KHz
• Mid +/-15dB @ 2,5 KHz
• Low +/-15dB @ 45 Hz

Stereo EQ:

• High: +/-15dB @ 12 KHz
• Low: +/-15dB @ 60 KHz

Other information:

• Multi-effect : 24-bit analog-to-digital converter, 16 programs
• Power supply : AC100~240V 50/60 Hz
• Size : (L x L x E) : 330 x 224 x 92 mm
• Weight : 3,5 Kg
