MOSCONI GLADEN PICO 1_V2

Automobilinis 1-no kanalo D klasės labai mažas garso stiprintuvas 1×900 W @ 1 ohm

1 channel PWM amplifier

Mosconi Pico 1 V2
1 channel amplifier
Class D technology
Up to 750 Watts @ 2 Ohm
12V and 18V Version

Overview Mosconi Pico 1 V2
Full-range PWM amplifier with separate, synchronized modulation and fast high-current mosfets. The Mosconi PICO 1 delivers a full 900 Wrms into 1 ohms. It provides necessary power even to powerful subwoofers and extreme front systems at any time.

Ideal (subwoofer) supplement to a Mosconi PICO DSP amplifier, but with the high-level and low-level input and its own filters, it can also be used universally.

Automatic switch-on (only high level, SE or BTL mode)
Remote volume control (optional)
Molex connectors

Technical Data Mosconi Pico 1 v2
OUTPUT POWER:
Output power RMS @ 4Ω: 1 x 350 Watts
Output power RMS @ 2Ω: 1 x 600 Watts
Output power RMS @ 1Ω: 1 x 900 Watts

Specifications:
Input voltage: 0,3 V – 20 V
Overall efficiency: > 75 %
Auto-On (only High Level): Off – BTL
Low-pass filter: Off / 45 – 310 Hz (12 dB/Oct)
Subsonic filter (always on) : 13 Hz (12 dB/Oct)
Dimensions: 150 x 115 x 46 mm
Weight: 1050 Gramm
